General Protection,high surge 通用型保護，大浪涌
顯示種產(chǎn)品
| Model |
Channel
|
VRWM (V) max
|
Vbr (V) min
|
Vc (V) max
|
Contact discharge (kV) max
|
Air discharge (kV) max
|
Ipp (A) min (8/20uS)
|
Capacitance (pF) typ
|
Package
|
AEC-Q101
|
|---|---|---|---|---|---|---|---|---|---|---|
|
CSH03CU |
1 | 3.3 | 4 | 18 | +/-30 | +/-30 | 30 | 300 | SOD-323 | no |
|
CSH05CU |
1 | 5 | 6 | 20 | +/-30 | +/-30 | 30 | 300 | SOD-323 | no |
|
CSH12CU |
1 | 12 | 13.3 | 35 | +/-30 | +/-30 | 15 | 150 | SOD-323 | no |
|
CSH15CU |
1 | 15 | 16.3 | 45 | +/-30 | +/-30 | 10 | 120 | SOD-323 | no |
|
CSH24CU |
1 | 24 | 26 | 55 | +/-30 | +/-30 | 6 | 80 | SOD-323 | no |
|
CSH36CU |
1 | 36 | 40 | 75 | +/-30 | +/-30 | 3 | 60 | SOD-323 | no |
|
CSH03CB |
1 | 3.3 | 3.5 | 16 | +/-25 | +/-25 | 25 | 150 | SOD323 | no |
|
CSH05CB |
1 | 5 | 6 | 18 | +/-25 | +/-25 | 24 | 120 | SOD323 | no |
|
CSH08CB |
1 | 8 | 8.5 | 24 | +/-25 | +/-25 | 18 | 110 | SOD323 | no |
|
CSH12CB |
1 | 12 | 13.3 | 32 | +/-25 | +/-25 | 13 | 70 | SOD323 | no |
|
CSH15CB |
1 | 15 | 16.5 | 38 | +/-25 | +/-25 | 10 | 40 | SOD323 | no |
